M46 - M47 Field two part Panorama
with 10" f/3.9 Astrograph
Uploaded 3/10/23

This is the first official color image with our new CCD camera, the Atik 16200. There is some overlap here, but essentially this is two frames side by side. The Baader MPCC did a great job at keeping the stars sharp to the corners even with this larger APS-H chip which is 35mm diagonal.

M47 an open cluster is on the right and is a loose collection of mostly blue super giants. On the left we see M46 and the planetary nebula NGC2438 which lies some distance in front of this cluster in space. Between this planetary nebula and the top of the field you can see a small red disk - That is Minkowski 1-18 which is around 15.5 magnitude. And finally, halfway between the two clusters and close to the bottom is the dim cluster NGC2425 which is dominated by yellow super giants with a few blue ones mixed in. Other than those objects, there are a few background galaxies around magnitude 18.

Select an image size for a larger view 2000 x 768
Instrument: 10" f/3.9 Orion Astrograph Newtonian with Baader MPCC Mount: Astrophysics 1200 QMD CCD Camera: ATIK 16200 with Baader MPCC and Astronomik LRGB Guider: ASI120 w/80mm WO Zenithstar 81 piggyback refractor Exposure: 90m total both halves Astronomik RGB Combine Ratio: 1: 1.05: 1.2 Location: Payson, Arizona, Elevation: 5150 ft. Sky: Seeing FWHM = 3 arcsec , Transparency 4/10 Outside Temperature: 25 F CCD Temperature: -30 C Image Processing Tools: Maxim DL6: Calibration, PixInsight: All Remaining processing, Production finishing: Photoshop CS2 HOME GALAXIES EMISSION NEBS REFLECTION NEBS COMETS GLOBULARS OPEN CLUST PLANETARIES LINKS
